Product Description:
Key Benefits:
Thermal camera system
- Auto / manual focus support
- Support white hot / black hot / polarity switching
- Support 4x digital zoom
- Support picture in picture
- Support image brightness adjustment
- Size image contrast adjustment
- Display / Off of cross dash dimension image
Visible imaging mode
- Auto / manual focus support
- Support defogging function
- Support 10x Optical Zoom
- Support 4x digital zoom
- Support picture in picture
- Support image color saturation adjustment
- Image contrast adjustment
- Display / Off of cross dash dimension image
The Portable Infrared Camera also offers convenient storage options, saving all recorded footage in MP4 format. This widely compatible format ensures that users can effortlessly transfer, view, and share their thermal videos and images across various devices and platforms. Whether you need to review your data on a computer, smartphone, or other media player, the MP4 storage format provides flexibility and ease of access.
Overall, the Portable Infrared Camera is a versatile and reliable tool that combines innovative technology with user-friendly features. Its multiple image modes, advanced night vision infrared system, and 915nm NIR laser make it an indispensable device for hunting and border defense applications. As a Lightweight IR Photo Camera and handheld thermal imager, it delivers exceptional performance in a compact and portable package, empowering users to detect and identify heat signatures with confidence and precision.
Technical Parameters:
| HP-MFC6107-2KM |
| Thermal Imager |
| Wavelength range |
8mm~14mm |
| Detection distance |
7km for vehicle, 3km for human |
| Identification distance |
2km for vehicle,1km for human |
| Field of view angle |
≥6° x 4.5° |
| Lens parameters |
71mm |
| Detector parameters |
640 x 512 |
| Visible Imager |
| Recognition distance (2.3m x 4.7m target) |
≥6km |
| Recognition distance (1.8m x 0.5m person) |
≥3km |
| Lens parameters |
10x Optical Zoom |
| Focal length |
5.1mm~51mm |
| Detector type |
Full HD Color Detector |
| Electron doubling |
1X ~ 4X |
| Pixel parameters |
1920×1080 |
| Laser Rangefinder |
| Maximum range |
≥2km |
| Minimum range |
≤5m |
| Ranging accuracy |
±1m |
| wavelength |
900 ~ 908nm |
| Digital Compass |
| Horizontal positioning accuracy |
≤5m(CEP) |
| Elevation positioning accuracy |
≤10m(PE) |
| Angle measurement accuracy |
≤0.5° |
| Image Display |
| Type of OLED |
1920 X 1080 Colour OLED |
| Digital Zoom |
1X ~ 4X |
| Palette |
White Hot, Black Hot, Red Hot, Pseudo Colour |
| Interface |
| Standard Interface |
USB, Video, RS232;12V Adapter |
| External Power Supply Interface |
Power Input Range: 9V ~ 28V |
| Video Storage |
| Image Size |
1920 x 1080 (Visible);640 x 512 (Infrared) |
| Video |
1920 x 1080@25Hz |
| SD and Storage time |
128G;8 hours |
| Power supply |
| Battery |
18650/4 Batteries |
| Operational Hour |
6 hours (Under room temperature) |
| Environmental Adaptive and Physical Characteristic |
| Operation Temperature Range |
-40°C ~ ﹢55°C |
| Protection |
IP66 |
| Weight |
1.6kg |
Applications:
City safety, border surveillance, railway security, night gathering evidence
Company:
Hope Wish Photoelectronics Technology Co., Ltd. was established in Jinan high tech Zone and has a core R&D team for laser imaging, infrared thermal imaging detection and tracking technology research and product. Hope-Wish focuses on the research and development of night vision and multispectral imaging technology, by using a variety of image analysis and processing technology based on artificial intelligence to provide users with comprehensive optoelectronic system solutions in long-distance, high-definition, intelligent, multi-purpose, all-weather and complex environments.
Hope-Wish solutions cover the border/coastal defense, anti UAV, intelligent transportation, forest fire prevention, environmental protection, individual photoelectric equipment (handheld, helmet, gun aiming), marine and other industries. The products developed by the Hope-Wish, with their excellent performance, reliable quality and thoughtful after-sales service has been widely praised by users all over the world.
