Product Details:
|
| Power Supply: | 5V DC | Image Resolution: | 640 X 512 |
|---|---|---|---|
| Temperature Range: | -20°C To +120°C | Storage Temperature: | -40°C To +70°C |
| Product Name: | Dual Thermal Camera | Interface: | USB 2.0 |
| Field Of View: | 45° X 34° | Humidity: | 0 To 95% RH |
| Highlight: | Dual Thermal Long Range Security Camera,Dual Thermal Imaging Camera 5V DC,Long Range Security Thermal Imaging Camera |
||
Overview
| Model | HP-TVC6511-2150 |
| Detection | Vehicle: 8.6km,Human:3.4km |
| Identification | Vehicle:2.4km, Human: 900m |
| Thermal Camera System | |
| Sensor | 5th generation FPA VOx uncooled detector |
| 640*512 resolution (optional 384*288 resolution) | |
| Spectral range | 7.5～14μm |
| NETD | 50mK (@25℃ F1.0) |
| Focal length | 25mm~105mm, 5X continuous zoom, auto focus |
| FOV | 30°X23°~6.2°X4.6° |
| Image process |
1. Image enhancement: SDE digital image enhancement technology to enhance image details 2. Pseudo-color polarity: 16 kinds of pseudo-color images, hot black / hot white two polarities 3. Image parameters: AGC automatic gain control, brightness, contrast 4. Electronic zoom: 2×, 4×, support global synchronous display 5. NUC correction: automatic / manual correction, background correction |
| Lens Control |
1.Zooming: Electrical Zoom. 2.Focusing: Manual/Auto Focus 3. Optical machine: 3CAM mode and AS+DOE optical structure, high infrared over transmission, zoom process without virtual focus, smaller axis. |
| Visible Camera System | |
| Camera | 1/2.8” star level CMOS, 0.05lux/0.01lux color to B/W CCD |
| 2 MP ,1920X1080 | |
| Automatic ICR switch | |
| H.264/H.265 MPEG4/MIPEG | |
| 32Kbps~16Mbps,60Hz30 FPS | |
| Visible lens | 8mm～320mm, 2MP, 40X zoom, auto focus |
| Optical IR correction design, diurnal focus | |
| Housing | |
| Material | High strength aluminum alloy shell,waterproof seal,To avoid the growth of mold and moisture generated |
| Structure | Integrated single-window design |
| Surface coating | PTA three-resistance coating, Seawater corrosion resistance |
| Temp. Control | Built-in thermostat, design of thermal equilibrium |
| Interface | Aviation waterproof plug |
| PTZ | |
| Load Capacity | 30kg |
| Range/Speed | Range:Pan: 0~360°, Tilt: +45°～-45°; Speed: Pan: 0.01～60°/S, Tilt: 0.01～30°/S |
| Preset | 255 |
| Scan | Support 6 cruising line, 1 apple-skin scanning, 1 line-cruising. |
| Interface | |
| Network Interface | RJ45 |
| Network Protocol | Support TCP/IP, UDP, IPv4/v6; Support HTTP,RTP,RTSP,NFS,HDCP,NTP,SMTP,,PPPoE,DNS, FTP, Onvif |
| Power Supply | AC/DC24V, anti-reverse connection protection |
| Environment Parameter | |
| Working/Storage Temp. | Working temperature: -25℃~+60℃(-40℃for optional); Storage temperature: -45℃~70℃ |
| Seismic/Impact Resistance | 0.2g/15g |
| Anti-lighting | Built-in auto Fuse-protected device, Power 4000V,Signal 2000V |
| Weight & Power Consumption | |
| Weight: 35kg (include PT); Power consumption: 150W | |
Hope Wish Photoelectronics Technology Co., Ltd. was established in Jinan high tech Zone and has a core R&D team for laser imaging, infrared thermal imaging detection and tracking technology research and product. Hope-Wish focuses on the research and development of night vision and multispectral imaging technology, by using a variety of image analysis and processing technology based on artificial intelligence to provide users with comprehensive optoelectronic system solutions in long-distance, high-definition, intelligent, multi-purpose, all-weather and complex environments.
