Real Time Small Ptz Ir Thermal Imaging Camera For Cars / Ships Surveillance

Real Time Small Ptz Ir Thermal Imaging Camera For Cars / Ships Surveillance

    • Real Time Small Ptz Ir Thermal Imaging Camera For Cars / Ships Surveillance
    • Real Time Small Ptz Ir Thermal Imaging Camera For Cars / Ships Surveillance
  • Real Time Small Ptz Ir Thermal Imaging Camera For Cars / Ships Surveillance

    Product Details:

    Place of Origin: China
    Brand Name: Hope-Wish
    Certification: CE,FCC
    Model Number: BTVC4105A-1930-IP

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 pc
    Price: Negotiable
    Packaging Details: wooden case
    Payment Terms: L/C, T/T, Western Union
    Contact Now
    Detailed Product Description
    NETD: 50mK Image Processing: 10 Pseudo Color And B/W, B/W Inverse
    PTZ: Duty: 50kg Resolution: 336*256/640*512
    Type: Day&night Camera Feature: IP66
    High Light:

    thermal security camera

    ,

    long range ptz camera



    Real Time Small Ptz Ir Thermal Imaging Camera For Cars / Ships Surveillance



    Feature

    1.  24-hour real time surveillance is ensured with both thermal and visible camera.
    2.  50mk thermal sensitivity and SDE digital image enhancement produces clearer image under foggy and rainy days.
    3.  Anti-lighting, anti-wave, capability to withstand 3000V instantaneous current.
    4.  Aluminum alloy housing, excellent heat dissipation, IP65 ingress protection.



    Application
    vehicle mounted surveillance ,police get evidence.City safety, oilfield safety, railway security,


    Technical specification

    Model BTVC4102A-1930-IP BTVC4105A-1930-IP BTVC4307A-2132-IP
    Detection Vehicle: 1700m Vehicle: 4200m Vehicle: 6300m
    Human: 720m Human: 1640m Human: 2500m
    Identification Vehicle: 420m Vehicle: 1200m Vehicle: 1800m
    Human: 180m Human: 470m Human: 700m
    Thermal sensor 336*256, UFPA, 7-14um spectral response, 50mk NETD
    Thermal lens 20mm F1.0 50mm F1.0 25~75mm
    FOV 15.5°× 11.6° 6.5×4.8° 13°×10°~4.3°×3.2°
    Visible sensor 2 mega pixels, auto color to B/W CMOS at 0.01Lux
    Visible Lens 4.3mm ~ 129mm , 30X optical, motorized zoom, auto focus 8~320mm optical zoom,auto focus
    Pan 0° to 360° continuous
    Tilt -90°~+90°
    Pan speed 0°~100°/s
    Tilt speed 0°~60°/s
    Preset 128
    Scan 3(user can set the starting and end point; adjustable
    Path 6(16 points for each path, adjustable duration on each point)
    Pattern 3(approx. 2 minutes for each pattern)
    Menu language English
    Auto homing Homing time(1-99mins), homing action(preset/scanning/path/pattern)
    Protocol Pelco-D/P and other mainstream protocols
    Baud rate 2400/4800/9600/19200bps
    Heating/defrosting/Wiper Available
    Interface 1* BNC analog thermal video, 1* HD IP visible video, 1 *RS485 control, 1 AC24V/DC24V
    Ingress protection IP66
    Working temp. -35~55 ℃
    Power supply AC24V/2.5A
    Weight 7kg

    * The detection distance is related to the object and environment etc. Please contact with us for further information.



    Real Time Small Ptz Ir Thermal Imaging Camera For Cars / Ships SurveillanceReal Time Small Ptz Ir Thermal Imaging Camera For Cars / Ships Surveillance
