Product Details:
|
| NETD: | 50mK | Storage Temperature: | -35 ℃～ +75 ℃ |
|---|---|---|---|
| Operating Temperature: | -25 ℃～ +55 ℃（ -40 ℃ Optional ） | Resolution: | 640*512 |
| Technology: | PTZ | Feature: | IP66 |
| High Light: | thermal security camera,long range ptz camera,IP66 rate dual thermal camera |
||
Fishery Safety Dual Sensor Thermal Imaging Camera With IP Control Electronic System
Feature:
Application
City safety, oilfield safety, railway security, night gathering evidence.
Technical specification
| Model | TVC4307A-2132-IP | TVC4511A-2050-IP |
| Detection | Vehicle: 6300m | Vehicle: 8600m |
| Human: 2500m | Human: 3400m | |
| Identification | Vehicle: 1800m | Vehicle: 2400m |
| Human: 700m | Human: 900m | |
| Thermal sensor | VOx uncooled detector, 324*256(640*512 optional) / 7.5um-14um spectral response, 50mk NETD | |
| Thermal lens | 25mm ～ 75mm | 21mm ～ 105mm |
| 1. Electric zoom and focus (option auto focus) | ||
| Fov ( H ) | 13° ～ 4.3° | 18° ～ 3.4° |
| Image process | 2X digital zoom; Image processing; AGC; 10 pseudo color; SDE image enhancement; | |
| Visible sensor | 1/2.8'' CMOS | 1/1.8'' CMOS |
| 0.01lux color to B/W CCD | 0.0002lux super high sensitive color to B/W CCD | |
| 2.1MP ,1920X1080 | 2 megapixels,1920X1080 | |
| Automatic ICR switch | Automatic ICR switch | |
| H.264/MPEG4/MIPEG | H.264/MPEG4/MIPEG | |
| Visible lens | 8mm～320mm | 15mm～528mm |
| Electric zoom and focus | infrared correction/ motorized zoom | |
| Electric zoom and focus | auto aperture | |
| Fog filter | No | AFR color fog filter technology |
| Housing | Material : High strength aluminum alloy shell , waterproof seal , To avoid the growth of mold and moisture generated | |
| Interface : Aviation waterproof plug | ||
| PTZ | Load : 30kg | |
| Range : Pan: 0~360°, Tilt: +40° ～ -45° | ||
| Speed : Pan: 0.01 ～ 50°/S, Tilt: 0.01 ～ 30°/S | ||
| Preset: 80, with Petrol/scan function | ||
| Azimuth real-time display, Zero correction function | ||
| Interface | Intelligent IP box , one 110M/100M adaptive Ethernet port (include thermal+HD visible+RS485) , 1* AC24V/DC24V adapter | |
| Video format | H.264, Dual video output | |
| Protocol | TCP/IP , HTTP , DHCP , DNS , DDNS , RTP ect. Other protocol | |
| Support ONVIF2.0 | ||
| Pelco-P , Pelco-D , Baudrate 2400 , 4800 , 9600 , 19200 optional | ||
| Power supply | AC24V/DC24V±10% , 50Hz , 150W , Standard AC220V->AC24V power supply (Optional DC12V) | |
| Environment | Operating temperature : -25 ℃～ +55 ℃( -40 ℃ optional ) | |
| Storage temperature : -35 ℃～ +65 ℃ | ||
| Humidity : <90% | ||
| Anti-lighting : built-in auto Fuse-protected device, Power 4000V , Signal 2000V | ||
| Ingress protection : IP66 | ||
| Weight | ≤25kg | ≤30kg |
