Military Grade Thermal Imaging Binoculars Hot White With Uncooled UFPA Sensor

Military Grade Thermal Imaging Binoculars Hot White With Uncooled UFPA Sensor

    • Military Grade Thermal Imaging Binoculars Hot White With Uncooled UFPA Sensor
    • Military Grade Thermal Imaging Binoculars Hot White With Uncooled UFPA Sensor
    • Military Grade Thermal Imaging Binoculars Hot White With Uncooled UFPA Sensor
    • Military Grade Thermal Imaging Binoculars Hot White With Uncooled UFPA Sensor
  • Military Grade Thermal Imaging Binoculars Hot White With Uncooled UFPA Sensor

    Product Details:

    Place of Origin: China
    Brand Name: Hope-Wish
    Certification: CE,FCC
    Model Number: MTC6107

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 pc
    Price: Negotiable
    Packaging Details: wooden case
    Payment Terms: L/C, T/T, Western Union
    Contact Now
    Detailed Product Description
    Color Mode: Hot-white/Hot-black Spectral Range: 7.5~14μm
    Sensor: Uncooled UFPA Sensor Resolution: 640*512
    Battery: 2xlithium Battery,25500,3000 MAh Using Life: > 500 Times
    High Light:

    infrared night vision binoculars

    ,

    thermal camera binoculars

    Military Grade Long Range Infrared Handheld Thermal Imaging Binoculars



    MTC series portable thermal camera is specially designed for mobile observation. With the latest the 5th generation uncooled infrared technology, unique imaging circuit components and AS optical design, it could search and observe object effectively in 5km. It have advantage like low weight, low consumption.



    MTC camera is equipped with a high-quality rubber soft cover as per human hands design, which suit both portable and fixed observation, for night collecting evidence, search targets. One integral aluminum alloy housing and sealed with nitrogen, IP66 protection to enable the camera works well in severe weather conditions.



    Feature

    1.  5th generation uncooled thermal sensor, decrease the size, weight and cost.
    2.  Aluminum alloy housing, weatherproof rate IP65, anti-rain, anti-dust.
    3.  NETD up to 50mk, higher sensitivity, little effect by rain, fog, and snow, obtain more delicate picture.
    4.  Unique AS optical design and high precision optical mechanical design, excellent image quality.
    5.  Excellent non-uniform image correct technology, good image and dynamic range, without TEC thermostatic control.
    6.  SDE image detail enhancement technology, no noise, B/W and B/W inverse color mode.

    Application

    Police , military, navy, night gathering evidence.

    Technical specification

    Model MTC6105R MTC6107R MTC6107RG
    Detection Vehicle 3800m Vehicle 5800m
      Human 1300m Human 2000m
    Identification Vehicle 970m Vehicle 1460m
      Human 400m Human 600m
    Sensor 5th generation UFPA
    Resolution 640*512(336*256 optional)
    Wave length 7.5~14μm
    Digital zoom 2x ; 4 x
    Color mode Hot-white/Hot-black
    Lens 50mm, F1.0 75mm, F1.0
    FOV 10°*8° 5.4°*4.1°
    Eyepiece display 640*480 , LCOS binocular display with eyeshade, high hidden 800*600 ,OLED binocular display with eyeshade, high hidden
    Image storage/video 4G memory card, 1000photos in JPEG format, video for 3.5 hours in AVI format, USB export
    ECO mode Auto
    Operation Four buttons, two at each side
    Battery parameter Operation voltage DC: +2.6V~+5.5V;
    Power consumption<2.8W (video time);
    2xlithium battery,25500,3000 mAh ;
    Continuous working time : > 5 hours at no record, >3.5 hours at record.
    Using life > 500 times , charge/ discharge cycles
    Starting time <3s
    Interface Video output micro USB Video output
    Weatherproof IP66
    Humidity 5%~95%(non-condensing
    Storage temperature -30℃~+70℃ -40℃~+70℃
    Operation temp. -20℃~+60℃ -35℃~+60℃
    Weight <400g <1.5kg (Included battery)
    Dimensions 158(L)*62(L)*66(L)mm 170(L)*168(L)*76(L)mm
    Accessories Video cable, lens cap, rubber covert, charger, lithium battery, suitcase

    * The detection distance is related to the object and environment etc. Please contact with us for further information.
