Thermal Surveillance System Long Distance Multi Sensor Thermal Camera for Perimeter Security Applications

Product Description:

The Thermal Surveillance System is an advanced security solution designed to deliver exceptional performance in various monitoring and detection scenarios. Equipped with a high-resolution infrared camera module, this system provides unparalleled thermal imaging capabilities that enable accurate detection and identification of objects in complete darkness, adverse weather conditions, and challenging environments. The core of this product centers around a cutting-edge thermal infrared camera, making it an indispensable tool for security, defense, and industrial applications.

At the heart of the Thermal Surveillance System is a superior uncooled sensor detector that ensures reliable and consistent thermal imaging without the need for complex cooling mechanisms. This technology not only reduces maintenance requirements but also enhances the system's durability and efficiency. The thermal infrared camera module boasts a primary resolution of 640x512 pixels, delivering crisp and clear thermal images that facilitate precise monitoring. For users requiring even greater detail, an optional upgrade to a 1280x1024 resolution is available, significantly enhancing image clarity and detection accuracy.

Z201 Series Long Range Multi Sensor Thermal Camera integrates HD daylight camera, uncooled thermal camera, gyro stabilization, intelligent analysis, and precise electronic control. It is designed for ship /shipboard video acquisition and sea surface warning, key target warning, radar linkage and other applications designed long distance detection system, which can adapt to all-weather, all-time, full-dimensional discovery, positioning, tracking, identification and tracking of the target function, the smallest distance to small ships and islands can be up to 10 km.

Features:

1.Multi spectrum: Integrated with HD daylight camera system, uncooled sensor thermal camera system,, and so on. Combined with active and passive detection, 24 hours surveillance in all-weather environments.

2.High/Fast turning speed: turning speed 90°/s, acceleration 120°/s², helpful for capture and tracking fast moving targets.

3.Wide coverage: the azimuth rotation range is 0~360°, and the pitch rotation range is -90° ~+90°, all angle detection, all-round coverage.

4.High control accuracy: using precision angle encoder and high precision servo PT control system, the positioning accuracy can reach 0.02°, high performance imaging processing technology combined with high precision focus control to achieve precise auto focus.

5. Excellent tracking performance: The automatic tracking module is designed with a variety of target acquisition algorithms and tracking algorithms, supplemented by high-precision servo control, to ensure stable tracking of the target during rapid movement and process.

6.Gyro stabilization: The two-axis gyro stabilization structure design effectively isolates the disturbance of the optical system caused by carriers such as vehicles and ships, and always maintains a high degree of image and video stability.

7. Intelligent analysis: Support target intrusion detection, motion detection and other abnormal behavior detection, support target classification and identification, support hot spot alarm, radar linkage, 3D zoom positioning and other functions.

8. Self-diagnosis and self-recovery: support life-cycle management, fault self-checking, front-end storage, resuming transmission after disconnection, memory after power failure, remote restart/upgrade.

9. Environmental adaptability: high-strength aluminum alloy material, internal and external double-layer three-proof technology, IP67 protection, rain-proof, dust-proof, anti-corrosion, anti-electromagnetic interference

Technical Parameters:

Applications:

l Seaport and airport monitoring;

l Water system monitoring;

l Storage monitoring;

l MIL base security monitoring;

l Oilfield & oil depot security;

l Fire source prevention & monitoring;

l Ecological and environmental monitoring;

l Border and coastal defense;

l Urban security and anti-UAV applications;

l Highways and railways monitoring.

Company:

Hope Wish Photoelectronics Technology Co., Ltd. was established in Jinan high tech Zone and has a core R&D team for laser imaging, infrared thermal imaging detection and tracking technology research and product. Hope-Wish focuses on the research and development of night vision and multispectral imaging technology, by using a variety of image analysis and processing technology based on artificial intelligence to provide users with comprehensive optoelectronic system solutions in long-distance, high-definition, intelligent, multi-purpose, all-weather and complex environments.

Hope-Wish solutions cover the border/coastal defense, anti UAV, intelligent transportation, forest fire prevention, environmental protection, individual photoelectric equipment (handheld, helmet, gun aiming), marine and other industries. The products developed by the Hope-Wish, with their excellent performance, reliable quality and thoughtful after-sales service has been widely praised by users all over the world.

FAQ:

Q1: What is the brand and model number of the Thermal Surveillance System?

A1: The Thermal Surveillance System is manufactured by Hope-Wish, and the model number is HP-Z201.

Q2: What type of technology does the HP-Z201 Thermal Surveillance System use?

A2: The HP-Z201 uses advanced thermal imaging technology to detect heat signatures for effective surveillance in various environments.

Q3: Can the Hope-Wish HP-Z201 Thermal Surveillance System operate in complete darkness?

A3: Yes, the HP-Z201 is designed to perform accurately in total darkness by detecting thermal radiation, making it ideal for night surveillance.

Q4: Is the HP-Z201 suitable for outdoor use?

A4: Yes, the Hope-Wish HP-Z201 is built with durable materials and weather-resistant features, making it suitable for outdoor surveillance applications.

Q5: What is the typical range of detection for the HP-Z201 Thermal Surveillance System?

A5: The HP-Z201 can detect heat signatures from a considerable distance, typically up to several hundred meters, depending on the environment and target size.
