Product Details:
|
| Detection: | Vehicles:4200m Human: 1640m | Warranty: | One Year |
|---|---|---|---|
| Recognition: | Vehicles:1800m Human: 800m | Image Output: | HDMI, USB |
| Digital Zoom: | 16x | Feature: | IP66 |
| Lens: | 31-155mm | Alarm: | Motion Detection, Temperature Alarm |
| Resolution: | 640x480 Pixels | Interface: | Remote OSD Setting |
| Ingress Protection: | IP66 Weatherproof | Rotation Speed: | Pan: 9°/S, Tilt: 4°/S |
| Operating Temperature: | -40°C To +65°C | Network Protocols: | ONVIF, RTSP, HTTP |
| Onvif: | Support | Lens Control: | Auto Focus |
| Operational Temperature: | -35°~55°(-45° Option ) | Type: | Thermal Camera |
| Housing: | Aluminum Alloy Housing | Storage Temperature: | -30°C To +70°C |
| Highlight: | PTZ thermal imaging camera with motion detection,long distance thermal camera for perimeter security,dual sensor thermal imaging camera with alarm |
||
l Unique AS + DOE advanced optical continuous zoom design and 3CAM high precision optical machine design, stable and
smooth zooming, which to conduct to large-scale searching and long-range recognition
l Excellent non-uniform image correction technology with good image uniformity and dynamic range
l SDE image detail enhancement technology, image smooth and noiseless, a variety of pseudo-color and hot black hot white
polarity image mode switching, adaptability, easy to find low-contrast hidden targetse.
The PTZ Thermal Imaging Camera is a state-of-the-art long range security camera designed to deliver exceptional performance in various surveillance and monitoring applications. Equipped with advanced thermal infrared camera technology, this device provides reliable detection and recognition capabilities even in complete darkness, adverse weather conditions, or challenging environments where traditional cameras fall short. Its infrared camera module is engineered to capture thermal signatures with high precision, allowing users to identify and track objects based on their heat emissions.
One of the standout features of this PTZ Thermal Imaging Camera is its impressive recognition range. It can detect vehicles up to 1800 meters away and recognize human figures at distances of up to 800 meters. This capability makes it an ideal choice for perimeter security, border control, traffic monitoring, and critical infrastructure protection. The long-range detection capability ensures that security personnel can respond promptly to potential threats or intrusions, enhancing overall safety and situational awareness.
|
Model |
HP-TVC6511-2150 |
|
Detection |
Vehicle: 8.6km,Human:3.4km |
|
Identification |
Vehicle:2.4km, Human: 900m |
|
Thermal Camera System |
|
|
Sensor |
5th generation FPA VOx uncooled detector |
|
640*512 resolution (optional 384*288 resolution) |
|
|
Spectral range |
7.5~14μm |
|
NETD |
50mK (@25℃ F1.0) |
|
Focal length |
25mm~105mm, 5X continuous zoom, auto focus |
|
FOV |
30°X23°~6.2°X4.6° |
|
Image process |
1. Image enhancement: SDE digital image enhancement technology to enhance image details 2. Pseudo-color polarity: 16 kinds of pseudo-color images, hot black / hot white two polarities 3. Image parameters: AGC automatic gain control, brightness, contrast 4. Electronic zoom: 2×, 4×, support global synchronous display 5. NUC correction: automatic / manual correction, background correction |
|
Lens Control |
1.Zooming: Electrical Zoom. 2.Focusing: Manual/Auto Focus 3. Optical machine: 3CAM mode and AS+DOE optical structure, high infrared over transmission, zoom process without virtual focus, smaller axis. |
|
Visible Camera System |
|
|
Camera |
1/2.8” star level CMOS, 0.05lux/0.01lux color to B/W CCD |
|
2 MP ,1920X1080 |
|
|
Automatic ICR switch |
|
|
H.264/H.265 MPEG4/MIPEG |
|
|
32Kbps~16Mbps,60Hz30 FPS |
|
|
Visible lens |
8mm~320mm, 2MP, 40X zoom, auto focus |
|
Optical IR correction design, diurnal focus |
|
|
Housing |
|
|
Material |
High strength aluminum alloy shell,waterproof seal,To avoid the growth of mold and moisture generated |
|
Structure |
Integrated single-window design |
|
Surface coating |
PTA three-resistance coating, Seawater corrosion resistance |
|
Temp. Control |
Built-in thermostat, design of thermal equilibrium |
|
Interface |
Aviation waterproof plug |
|
PTZ |
|
|
Load Capacity |
30kg |
|
Range/Speed |
Range:Pan: 0~360°, Tilt: +45°~-45°; Speed: Pan: 0.01~60°/S, Tilt: 0.01~30°/S |
|
Preset |
255 |
|
Scan |
Support 6 cruising line, 1 apple-skin scanning, 1 line-cruising. |
|
Interface |
|
|
Network Interface |
RJ45 |
|
Network Protocol |
Support TCP/IP, UDP, IPv4/v6; Support HTTP,RTP,RTSP,NFS,HDCP,NTP,SMTP,,PPPoE,DNS, FTP, Onvif |
|
Power Supply |
AC/DC24V, anti-reverse connection protection |
|
Environment Parameter |
|
|
Working/Storage Temp. |
Working temperature: -25℃~+60℃(-40℃for optional); Storage temperature: -45℃~70℃ |
|
Seismic/Impact Resistance |
0.2g/15g |
|
Anti-lighting |
Built-in auto Fuse-protected device, Power 4000V,Signal 2000V |
|
Weight & Power Consumption |
|
|
Weight: 35kg (include PT); Power consumption: 150W |
|
l Seaport and airport monitoring;
l Water system monitoring;
l Storage monitoring;
l MIL base security monitoring;
l Oilfield & oil depot security;
l Fire source prevention & monitoring;
l Ecological and environmental monitoring;
l Border and coastal defense;
l Urban security and anti-UAV applications;
l Highways and railways monitoring.
