Product Details:
|
| Protection Grade: | IP66, Waterproof And Dustproof | Image Process: | DDE |
|---|---|---|---|
| Grade: | Military Grade | Detection Range: | Up To 5km |
| Lens: | Motorized & Manual Focus | Detection: | 1-20km |
| Temperature Range: | -40°C To 1200°C | Lrf: | Optional 5km,8km,15km |
| Highlight: | 1-20km Thermal Surveillance System,Military Grade Thermal Surveillance System,Advanced Thermal Surveillance System |
||
Key Benefits:
With a temperature range of -40°C to 1200°C, this system excels in detecting and tracking objects based on their thermal signatures, making it especially effective in low-light or challenging environmental conditions. The high temperature range ensures that even subtle temperature variations are captured accurately, enhancing the system's surveillance capabilities.
When it comes to power efficiency, the Thermal Surveillance System is designed to operate with maximum power consumption of 150W, ensuring reliable performance without excessive energy usage. This allows users to maintain continuous surveillance operations without worrying about power constraints, making the system a dependable choice for long-term monitoring tasks.
One of the standout features of the Thermal Surveillance System is its advanced Thermal PTZ Camera, which combines thermal imaging technology with a powerful 20x zoom lens to deliver exceptional surveillance capabilities. The camera's 1080p resolution and 2Mp sensor ensure crisp and clear imaging, capturing details with impressive accuracy.
Whether used for security monitoring, perimeter surveillance, or environmental monitoring, the Thermal Surveillance System offers a comprehensive solution for various surveillance needs. Its advanced features, long-range capabilities, and high-resolution imaging make it a valuable asset for enhancing situational awareness and security measures in diverse settings.
| Model | HP-DMS10-4300-20 |
| Detection |
vehicles:1700m human: 720m fire point (@2x2m): 1000m |
| Recognition |
vehicles:500m human: 200m |
| Thermal imaging Camera |
1.Detector: The sixth generation uncooled focal plane array VOx detector 2. Wavelength: 8～14μm 3. NETD:40mK(@25℃ F1.0) 4. Lens: 20mm 5. Image enhancement: SDE digital image enhancement technology, enhance the details of the image, support 255 thermal image enhancement adjustment 6.Pseudo-color polarity: 16 kinds of pseudo-color images, hot black/hot white 7.Image parameters: AGC automatic gain control, brightness, contrast 8.Electronic zoom: 1.0～8.0×continuous zoom (step length 0.1), support global eagle eye diagram 9. Ranging ruler: support for range finding ruler 10.Dead pixel correction: support the function of dead pixel correction 11.Image correction: support manual correction, background correction, automatic correction time interval, adjustable Gamma correction parameters 12.Strong light protection: support anti-sun damage 13.Non-uniformity correction: automatic/hand |
| Resolution | Pixel:384×288 |
| Visible Camera |
1.Sensor type: back-illuminated ultra-low illumination starlight CMOS 2.Minimum illumination: color: 0.0005Lux @ black and white: 0.0001Lux @ 0Lux(IRON) 3.Lens:7mm～330mm, 47 times optical zoom,16 times digital zoom. 4.Image processing: white balance, electronic shutter, frame accumulation, backlight compensation, glare suppression, 2D/3D digital noise reduction, electronic anti-shake, wide dynamic. 5.Day and night light: 0.4-0.75um visible light wide spectral window and 0.8-0.95um near-infrared spectral window day and night independent double light window, improve the signal-to-noise ratio of imaging light and stray light 6.Support electronic fog penetration and optical fog penetration |
|
Laser illuminator |
1.Laser Homogenization: new infrared GHT-III HD flood light source, no scattered particles 2.Laser angle: 3°~65° switchable 3.Laser distance: 300m |
| Video audio |
1.Thermal camera resolution:support 1920×1080；1280×1024；1280×960；1024×768；1280×720；704×576；640×512；640×480；400×300；384×288；352×288；352×240 2.Visible camera resolution:2592×1520；2560×1440；1920×1080；1280×1024；1280×960；1024×768；1280×720；704×576；640×512；640×480；400×300；384×288；352×288；352×240 3.Video encoding: H.265/H.264/MJPEG,multi-stream support 4.Video code rate:32Kbps～16Mbps 5.Audio encoding:G.711A/ G.711U/G726 6.Image flip: left and right / up and down / diagonal 7.OSD settings: Support OSD display settings for channel name, time, gimbal orientation, field of view, focal length, and preset bit name settings |
| Intelligent functions |
1. Fire detection alarm: threshold 255 levels, target size, number of targets 1-16 can be set, automatically select the most prominent target display, hot spot tracking 2. Intelligent analysis: support intrusion detection, boundary crossing detection, entering/leaving area detection, motion detection, wandering detection, people gathering, fast moving, target tracking, items left behind, items taken; people/vehicle target detection, face detection; and support 16 area settings; support intrusion detection people, vehicle filtering filtering function; support target temperature filtering filtering function 3. Automatic tracking: support single scene tracking/support multi-scene tracking/support panoramic tracking/support alarm linkage tracking 4. Intelligent information fusion: support 512 AR intelligent information fusion, support fire point, intelligent analysis of the recording logo information fusion, support orientation angle, field of view angle, focal length, multiplier information fusion 5.Image fusion: support 18 kinds of double light fusion mode, support picture-in-picture function 6.Alarm management: support for alarm capture and upload |
| Enhanced Features |
1. Distance measurement: support passive distance measurement; support optional laser distance measurement. 2. Support sound and light alarm: internal integrated tweeter + flashing light, support alarm sound customization. 3. Support alarm linkage fire fighting device. 4. Camera diagnostic functions: support disconnection alarm, support IP conflict alarm, support illegal access alarm (illegal access times, lock time can be set), support SD card abnormal alarm (SD space is insufficient, SD card error, no SD card), video masking alarm, anti-sun damage (support threshold, masking time can be set). 5. Whole life management: health index record function, support working time, shutter count, working temperature, limit temperature, etc.; zoom lens and head each motor working cumulative time, etc. 6. Support disconnection renewal. 7. Power failure memory: support can restore the position before power failure, preset point state, cruise state, line sweep state. 8. Remote maintenance: with fault query, self-test, remote restart function; online upgrade, remote upgrade. 9. Key frame setting: support key frame interval 100 levels adjustable. 10. Configuration file: support configuration file import and export function. 11. Web access: support WEB full function configuration, remote online upgrade. |
| PT |
1. Rotation speed: Horizontal: 0.01°/s～100°/s; Pitch: 0.01°/s～80°/s, support focal speed adaption. 2. Rotation angle: horizontal: 360° continuous rotation; pitch: -90°～+90° 3. Structure material: quasi-spherical design of micro-rotary, integrated 5-window multi-channel, fine cast high strength aluminium alloy material. 4. Window glass: infrared/visible high efficiency optical glass, clean film coating. 5. Surface coating: PTA triple anti-corrosion coating, anti-corrosion. 6. Wiper: support intelligent automatic wiper 7. Defrost: visible window defrost 8. Preset position cruise: 3000 preset positions, support 16 cruise routes, each can support 256 preset positions 9. Watch function: preset bit / pattern scan / cruise scan / vertical scan / frame scan / panorama scan / apple skin scan / horizontal fan sweep line scan 10. Support 3D frame selection zoom 11. Orientation information: support angle query/real-time return and positioning; support lens field of view return and positioning 12. Zero point correction: support northward zero point remote correction function |
| Electrical interface |
1. Communication and control: 1 *RJ45 Ethernet port; 2* alarm inputs, 1 *alarm output; 1 *audio input input, 1 *RS485 interface. 2. Protocol: Support HTTP, HTTPS, FTP, SMTP, DNS, NTP, RTSP, RTCP, RTP, TCP, UDP, ICMP, DHCP network protocols; support ONVIF and GB28181 protocols. 3. Development interface: Support HP-SDK secondary development |
| Enhanced Function |
1. Glare protection: support, anti-sun burn function 2. Temperature correction: no thermal image design, imaging resolution is not affected by temperature 3. Scene mode: support multiple configuration scenarios, adapt to no environment application 4. Auto focus tuning: support remote auto focus precision parameter adjustment, adapt to different scenes 5. Day and night cruise: day and night group cruise different preset groups, day cruise 1-40 preset position, night cruise 41-80 preset position, automatically switch day and night according to the photosensitive state, adapt to different time and space scenes 6. Lens servo: support lens preset position, focal length return, focus positioning function 7. Parameter setting: OSD menu remote call operation 8. Remote maintenance: support embedded program remote upgrade for easy after-sales maintenance |
| Safety control |
1. Support illegal access alarm: the number of illegal access, lock time can be set.
|
| Power supply |
1. Working voltage: DC 9~36V, external AC220V or battery power adapter
|
| Environmental adaptation |
1. Working temperature: -40℃～60℃
|
| Volume weight |
1. Weight: ≤10kg
|
· Seaport and airport monitoring;
· Water system monitoring;
· Storage monitoring;
· Oilfield & oil depot security;
· Ecological and environmental monitoring;
· Border and coastal defense;
· Highways and railways monitoring.
Thanks to its 20x zoom capability, the Hope-Wish Thermal Surveillance System enables users to focus on specific areas or objects of interest with precision and clarity. The integrated GPS feature with a positioning accuracy of 10 meters enhances situational awareness and tracking capabilities, making it suitable for security and surveillance applications that require accurate location data.
Operating with a maximum power consumption of 150W, this system offers efficient performance while minimizing power usage. The compact dimensions of 640 x 512 make it easy to install and integrate into different setups, providing flexibility and convenience for deployment in various scenarios.
Overall, the Hope-Wish Thermal Surveillance System is a versatile and advanced solution that caters to a wide range of surveillance needs, combining advanced features such as long-range detection, waterproof design, high-resolution thermal imaging, precise zoom capabilities, GPS tracking, and efficient power consumption. Whether used for security monitoring, perimeter protection, wildlife observation, or other applications, this thermal surveillance system delivers reliable performance and high-quality imaging for enhanced situational awareness.
Hope Wish Photoelectronics Technology Co., Ltd. was established in Jinan high tech Zone and has a core R&D team for laser imaging, infrared thermal imaging detection and tracking technology research and product. Hope-Wish focuses on the research and development of night vision and multispectral imaging technology, by using a variety of image analysis and processing technology based on artificial intelligence to provide users with comprehensive optoelectronic system solutions in long-distance, high-definition, intelligent, multi-purpose, all-weather and complex environments.
Product Customization Services for the Hope-Wish Thermal Surveillance System:
- Brand Name: Hope-Wish
- Model Number: HP-DMS
- Place of Origin: China
- Detection: 1-20km
- Lrf: Optional 5km, 8km, 15km
- Image Process: DDE
- Waterproof: IP67
- Grade: Military Grade
Q: What is the brand name of this Thermal Surveillance System?
A: The brand name of this Thermal Surveillance System is Hope-Wish.
Q: What is the model number of this Thermal Surveillance System?
A: The model number of this Thermal Surveillance System is HP-DMS.
Q: Where is this Thermal Surveillance System manufactured?
A: This Thermal Surveillance System is manufactured in China.
Q: What are the key features of the Hope-Wish HP-DMS Thermal Surveillance System?
A: The key features of this Thermal Surveillance System include high-resolution thermal imaging, real-time monitoring, and advanced motion detection capabilities.
Q: Is the Hope-Wish HP-DMS Thermal Surveillance System suitable for outdoor use?
A: Yes, this Thermal Surveillance System is suitable for outdoor use as it is designed to withstand various weather conditions.
