Product Description:
- Unique AS + DOE advanced optical continuous zoom design and 3CAM high precision optical machine design, stable and smooth zooming, which to conduct to large-scale searching and long-range recognition
- Excellent non-uniform image correction technology with good image uniformity and dynamic range
- SDE image detail enhancement technology, imagesmooth and noiseless, a variety of pseudo-color and hot black hot white polarity image mode switching, adaptability, easy to find low-contrast hidden targetse
Moreover, the Pan function of this thermal imaging camera allows for N × 360° continuous rotation, enabling seamless panoramic views of the surroundings. This capability ensures comprehensive coverage of the area under surveillance, minimizing blind spots and maximizing monitoring effectiveness.
Whether used for security, industrial inspection, or search and rescue operations, the Long Range Thermal Camera excels in providing reliable thermal imaging solutions for long-range applications. Its advanced features and high-performance capabilities make it a valuable asset for professionals seeking superior surveillance technology.
Features:
- Integrates with infrared thermal image, HD visible imaging, video coding, pan/tilt cover and control electronic system
- Visible imaging adopts with full HD color black and white mode low illumination CMOS sensor and 30 times
- compact continuous zoom lens
- The latest generation of VOx detectors based on MEMS technology, detection sensitivity (NETD) up to 50mk, higher sensitivity than conventional products, to obtain more delicate picture quality, less affected by fog, rain and snow switching of laser switch and camera into day-night mode
Technical Parameters:
| Model |
AGT-TVC6516-2186 |
| Detection |
Vehicle: 13km,Human:4.8km |
| Identification |
Vehicle:3.4km, Human: 1.3km |
| Thermal Camera System |
| Sensor |
5th generation FPA VOx uncooled detector |
| 640*512 resolution (optional 384*288 resolution) |
| Spectral range |
7.5～14μm |
| NETD |
50mK (@25℃ F1.0) |
| Focal length |
31mm~155mm, 5X continuous zoom, auto focus |
| FOV |
20°X 15°~4°X3°
|
| Image process |
1. Image enhancement: SDE digital image enhancement technology to enhance image details
2. Pseudo-color polarity: 16 kinds of pseudo-color images, hot black / hot white two polarities
3. Image parameters: AGC automatic gain control, brightness, contrast
4. Electronic zoom: 2×, 4×, support global synchronous display
5. NUC correction: automatic / manual correction, background correction
|
| Lens Control |
1.Zooming: Electrical Zoom. 2.Focusing: Manual/Auto Focus
3. Optical machine: 3CAM mode and AS+DOE optical structure, high infrared over transmission, zoom process without virtual focus, smaller axis.
|
| Visible Camera System |
| Camera |
1/1.8” star level CMOS, 0.001lux/0.0001lux color to B/W CCD |
| 2 MP ,1920X1080 |
| Automatic ICR switch |
| H.264/H.265 MPEG4/MIPEG |
| 32Kbps~16Mbps,60Hz30 FPS |
| Visible lens |
11～800mm, 2MP, 72X zoom, auto focus |
| Optical IR correction design, diurnal focus |
| Housing |
| Material |
High strength aluminum alloy shell,waterproof seal,To avoid the growth of mold and moisture generated |
| Structure |
Integrated single-window design |
| Surface coating |
PTA three-resistance coating, Seawater corrosion resistance |
| Temp. Control |
Built-in thermostat, design of thermal equilibrium |
| Interface |
Aviation waterproof plug |
| PTZ |
| Load Capacity |
50kg |
| Range/Speed |
Range:Pan: 0~360°, Tilt: +45°～-45°; Speed: Pan: 0.01～30°/S, Tilt: 0.01～15°/S |
| Preset |
255 |
| Scan |
Support 6 cruising line, 1 apple-skin scanning, 1 line-cruising. |
| Interface |
| Network Interface |
RJ45 |
| Network Protocol |
Support TCP/IP, UDP, IPv4/v6; Support HTTP,RTP,RTSP,NFS,HDCP,NTP,SMTP,,PPPoE,DNS, FTP, Onvif |
| Power Supply |
AC/DC24V, anti-reverse connection protection |
| Environment Parameter |
| Working/Storage Temp. |
Working temperature: -25℃~+60℃(-40℃for optional); Storage temperature: -45℃~70℃ |
| Seismic/Impact Resistance |
0.2g/15g |
| Anti-lighting |
Built-in auto Fuse-protected device, Power 4000V,Signal 2000V |
| Weight & Power Consumption |
| weight: 45kg (include PT); Power consumption: 180W |
|
|
- Seaport and airport monitoring;
- Water system monitoring;
- Storage monitoring;
- Military base security monitoring;
- Oilfield & oil depot security;
- Fire source prevention & monitoring;
- Ecological and environmental monitoring;
- Border and coastal defense;
- Urban security and anti-UAV applications;
- Highways and railways monitoring.
Manufactured in China, the HP-TTVC combines advanced technology with durable design, ensuring long-lasting performance in demanding environments. Its minimum focus distance of 5-10KM makes it versatile for different monitoring needs, while its user-friendly interface allows for easy operation and control.
Overall, the Hope-Wish HP-TTVC Long Range Thermal Camera is a highly versatile and reliable solution for anyone in need of a long-distance thermal camera. Whether used for surveillance, security, or other applications, this camera delivers exceptional performance and quality, making it a valuable asset in various scenarios and scenarios.
Company:
Hope Wish Photoelectronics Technology Co., Ltd. was established in Jinan high tech Zone and has a core R&D team for laser imaging, infrared thermal imaging detection and tracking technology research and product. Hope-Wish focuses on the research and development of night vision and multispectral imaging technology, by using a variety of image analysis and processing technology based on artificial intelligence to provide users with comprehensive optoelectronic system solutions in long-distance, high-definition, intelligent, multi-purpose, all-weather and complex environments.
Hope-Wish solutions cover the border/coastal defense, anti UAV, intelligent transportation, forest fire prevention, environmental protection, individual photoelectric equipment (handheld, helmet, gun aiming), marine and other industries. The products developed by the Hope-Wish, with their excellent performance, reliable quality and thoughtful after-sales service has been widely praised by users all over the world.Support and Services:
The Long Range Thermal Camera product offers comprehensive Product Technical Support and Services to ensure optimal performance and customer satisfaction. Our technical support team is dedicated to assisting customers with any product-related inquiries, troubleshooting issues, and providing guidance on product maintenance.
FAQ:
Q: What is the brand name of this thermal camera?
A: The brand name of this thermal camera is Hope-Wish.
Q: What is the model number of this thermal camera?
A: The model number of this thermal camera is HP-TTVC.
Q: Where is this thermal camera manufactured?
A: This thermal camera is manufactured in China.
Q: What is the maximum range of this long-range thermal camera?
A: The maximum range of this long-range thermal camera is X meters.
Q: Is this thermal camera suitable for night vision applications?
A: Yes, this thermal camera is suitable for night vision applications as it provides thermal imaging capabilities even in low light conditions.
