Product Details:
|
Alarm: | Motion Detection, Temperature Alarm | Humidity: | 95% RH |
---|---|---|---|
Focus: | Auto/Manual | Operating Temperature: | -20°C To +60°C |
Lens: | 35 Mm | Sensor: | Thermal Sensor |
Zoom: | 20x Optical Zoom | Type: | PTZ Thermal Imaging Camera |
High Light: | Dual Sensor PTZ Thermal Imaging Camera,Long Distance PTZ Thermal Imaging Camera,Vehicle Mounted PTZ Thermal Imaging Camera |
Unique AS + DOE advanced optical continuous zoom design and 3CAM high precision optical machine design, stable and smooth zooming, which to conduct to large-scale searching and long-range recognition
Excellent non-uniform image correction technology with good image uniformity and dynamic range
SDE image detail enhancement technology, image smooth and noiseless, a variety of pseudo-color and hot black hot white polarity image mode switching, adaptability, easy to find low-contrast hidden targetse
In conclusion, if you're in need of a high-quality long range security camera, the PTZ Thermal Imaging Camera is an excellent choice. With its powerful image processing capabilities, durable construction, and flexible positioning options, it's a versatile and reliable choice for a wide range of applications.
Integrates with infrared thermal image, HD visible imaging, video coding, pan/tilt cover and control electronic system
Visible imaging adopts with full HD color black and white mode low illumination CMOS sensor and 30 times compact continuous zoom lens
The latest generation of VOx detectors based on MEMS technology, detection sensitivity (NETD) up to 50mk, higher sensitivity than conventional products, to obtain more delicate picture quality, less affected by fog, rain and snow switching of laser switch and camera into day-night mode
Model | HP-TVC6307-2132 |
Detection | Vehicle: 6.5km,Human:2.5km |
Identification | Vehicle:1.8km, Human: 700m |
Thermal Camera System | |
Sensor | 5th generation FPA VOx uncooled detector |
Resolution | 640*512 (optional 384*288) |
Spectral range | 7.5~14μm |
NETD | 50mK (@25℃ F1.0) |
Focal length | 25mm~75mm, 3X continuous zoom, auto focus |
FOV | 24°X18°~8°X6° |
Image process |
1. Image enhancement: SDE digital image enhancement technology to enhance image details 2. Pseudo-color polarity: 16 kinds of pseudo-color images, hot black / hot white two polarities 3. Image parameters: AGC automatic gain control, brightness, contrast 4. Electronic zoom: 2×, 4×, support global synchronous display 5. NUC correction: automatic / manual correction, background correction |
Lens Control |
1.Zooming: Electrical Zoom. 2.Focusing: Manual/Auto Focus 3. Optical machine: 3CAM mode and AS+DOE optical structure, high infrared over transmission, zoom process without virtual focus, smaller axis. |
Visible Camera System | |
Camera | 1/2.8” star level CMOS, 0.05lux/0.01lux color to B/W CCD |
2 MP ,1920X1080 | |
Automatic ICR switch | |
H.264/H.265 MPEG4/MIPEG | |
32Kbps~16Mbps,60Hz30 FPS | |
Visible lens | 8mm~320mm, 2MP electric focus |
Optical IR correction design, diurnal focus | |
Housing | |
Material | High strength aluminum alloy shell,waterproof seal,To avoid the growth of mold and moisture generated |
Structure | Integrated single-window design |
Surface coating | PTA three-resistance coating, Seawater corrosion resistance |
Temp. Control | Built-in thermostat, design of thermal equilibrium |
Interface | Aviation waterproof plug |
PTZ | |
Load Capacity | 30kg |
Range/Speed | Range:Pan: 0~360°, Tilt: +45°~-45°; Speed: Pan: 0.01~60°/S, Tilt: 0.01~30°/S |
Preset | 255 |
Scan | Support 6 cruising line, 1 apple-skin scanning, 1 line-cruising. |
Interface | |
Network Interface | RJ45 |
Network Protocol | Support TCP/IP, UDP, IPv4/v6; Support HTTP,RTP,RTSP,NFS,HDCP,NTP,SMTP,,PPPoE,DNS, FTP, Onvif |
Power Supply | AC/DC24V, anti-reverse connection protection |
Environment Parameter | |
Working/Storage Temp. | Working temperature: -25℃~+60℃(-40℃for optional); Storage temperature: -45℃~70℃ |
Seismic/Impact Resistance | 0.2g/15g |
Anti-lighting | Built-in auto Fuse-protected device, Power 4000V,Signal 2000V |
Ingress Protection | IP 66 |
Hope Wish Photoelectronics Technology Co., Ltd. was established in Jinan high tech Zone and has a core R&D team for laser imaging, infrared thermal imaging detection and tracking technology research and product. Hope-Wish focuses on the research and development of night vision and multispectral imaging technology, by using a variety of image analysis and processing technology based on artificial intelligence to provide users with comprehensive optoelectronic system solutions in long-distance, high-definition, intelligent, multi-purpose, all-weather and complex environments.
Here are some frequently asked questions about the Hope-Wish PTZ Thermal Imaging Camera:
Q: What is the model number of this thermal imaging camera?
A: The model number of this thermal imaging camera is HP-TVC.
Q: Where was this thermal imaging camera manufactured?
A: This thermal imaging camera was manufactured in China.
Q: What is the brand name of this thermal imaging camera?
A: The brand name of this thermal imaging camera is Hope-Wish.
Q: What is the resolution of the thermal imaging sensor?
A: The thermal imaging sensor has a resolution of 640 x 480 pixels.
Q: What is the zoom range of the PTZ function?
A: The PTZ function allows for a zoom range of up to 30x, providing a clear view of distant objects.
