PTZ Cooled Sensor Thermal Imaging Camera Infrared Camera 90 Degrees Tilt Range 0.05lux Min Illumination

PTZ Cooled Sensor Thermal Imaging Camera Infrared Camera 90 Degrees Tilt Range 0.05lux Min Illumination
PTZ Cooled Sensor Thermal Imaging Camera Infrared Camera 90 Degrees Tilt Range 0.05lux Min Illumination PTZ Cooled Sensor Thermal Imaging Camera Infrared Camera 90 Degrees Tilt Range 0.05lux Min Illumination PTZ Cooled Sensor Thermal Imaging Camera Infrared Camera 90 Degrees Tilt Range 0.05lux Min Illumination

Large Image :  PTZ Cooled Sensor Thermal Imaging Camera Infrared Camera 90 Degrees Tilt Range 0.05lux Min Illumination

Product Details:
Place of Origin: China
Brand Name: Hope-Wish
Certification: CE, FCC, ROHS, ISO9001
Model Number: HP-CTC61532
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: wooden case
Delivery Time: 60-180
Payment Terms: L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 50 units per month

PTZ Cooled Sensor Thermal Imaging Camera Infrared Camera 90 Degrees Tilt Range 0.05lux Min Illumination

Description
Tilt Range: 90 Degrees Min Illumination: 0.05lux /0.005lux
Laser Angle: 2°~50° Optical Zoom: 30X
Ip Rating: IP66 Baud Rate: 2400/4800/9600/19200bps
Type: PTZ Camera Operating Temperature: -20°C To 60°C
High Light:

0.05lux Thermal Imaging Camera

,

Infrared Thermal Imaging Camera

,

PTZ Cooled Sensor Thermal Imaging Camera

Product Description:

  • 20mk NETD ensures premium thermal image.
  • Unique AS continuous optical zoom and 3CAM high precision mechanical engineering.
  • Superb inhomogeneous correction ensures crisp thermal image.
  • SDE image enhancement.
  • Aluminum alloy enclosure, IP 66 rated.

Whether you're looking to secure your home, office, or any other property, our IR Security Cameras are the perfect solution. With their powerful features and reliable performance, you can rest assured that your property is under constant surveillance.



Features:

  • Long range 24-hours monitoring.
  • Delicate and smooth images.
  • Convenient for installation and application.
  • 360 degree of Omni-directional Pan-Tilt
  • Super-strong aluminum alloy with IP66
  • Higher sensitivity
  • Effective in all environments
  • Small size and low weight

This PTZ Infrared Camera is an EO IR Camera that is perfect for outdoor use. It features an HD PTZ Outdoor Camera design that allows for clear and detailed footage. The camera uses a 808nm NIR laser and consumes 5W of power. It supports ONVIF and GB/T28181 compatibility and can operate in temperatures ranging from -20°C to 60°C. With a 30X optical zoom, this camera is perfect for capturing detailed footage from a distance.



Technical Parameters:

Model HP-CTC61532
Detection Vehicle: 18000m / Human: 11000m
Identification Vehicle: 7000m / Human: 3500m
Thermal Camera
Sensor

Cooled Focal Plane Array (FPA) MCT HgCdTe detector

Stirling cryocooler

Resolution 640 × 512 pixel
Spectral range 3.7 ~ 4.8μm, MWIR
NETD 20mK (@25℃ F4.0)
Focal length 15 - 300 mm
Field of view(horizontal) 35°×28°~1.8°×1.4°
PTZ
Duty 30kg CNC PT
Rotation Pan: 0~360°, Tilt: -45°~+45°
Rotation speed Pan: 0.01°~30°/S, tilt: 0.01°/S ~15°/S
Accuracy ±0.1°
Preset 255 presets, support lens zooming and focusing preset
Mode Support 6 cruising line, 1 apple-skin scanning, 1 line-cruising
Network
Network interface RJ45.10, 10/100 Base-T adaptive (integrated video output RS422/485)
Network Protocol TCP/IP, UDP, IPv4/v6; support HTTP, RTP, RTSP, NFS, DHCP, NTP, SMTP, SNMPv1/v2c/v3, UPNP, PPPoE, DNS, FTP; support PSIA, ONVIF2.0, GB28181 and other network protocol.
Environment Parameter
Operating temperature -25℃~+60℃(-40℃ Optional)
Storage temperature -45℃~70℃
Protection Level IP66
General
Total Consumption 180W
Power supply AC/DC24V, anti-reverse connection protection
Weight ≤25kg (include PTZ)


Applications:

  • Seaport and airport monitoring;
  • Water system monitoring;
  • Storage monitoring;
  • Military base security monitoring;
  • Oilfield & oil depot security;
  • Fire source prevention & monitoring;
  • Ecological and environmental monitoring;
  • Border and coastal defense;
  • Urban security and anti-UAV applications;
  • Highways and railways monitoring.

Company Profile:

Hope Wish Photoelectronics Technology Co., Ltd. was established in Jinan high tech Zone and has a core R&D team for laser imaging, infrared thermal imaging detection and tracking technology research and product. Hope-Wish focuses on the research and development of night vision and multispectral imaging technology, by using a variety of image analysis and processing technology based on artificial intelligence to provide users with comprehensive optoelectronic system solutions in long-distance, high-definition, intelligent, multi-purpose, all-weather and complex environments.

PTZ Cooled Sensor Thermal Imaging Camera Infrared Camera 90 Degrees Tilt Range 0.05lux Min Illumination 0
Hope-Wish solutions cover the border/coastal defense, anti UAV, intelligent transportation, forest fire prevention, environmental protection, individual photoelectric equipment (handheld, helmet, gun aiming), marine and other industries. The products developed by the Hope-Wish, with their excellent performance, reliable quality and thoughtful after-sales service has been widely praised by users all over the world.
PTZ Cooled Sensor Thermal Imaging Camera Infrared Camera 90 Degrees Tilt Range 0.05lux Min Illumination 1

Support and Services:

The PTZ Infrared Camera provides high-quality video surveillance for both indoor and outdoor environments. Our technical support team is available to assist with any installation or operation questions you may have. Additionally, we offer a range of services including maintenance and repair, firmware updates, and remote monitoring. Our goal is to ensure that your camera is functioning optimally and providing reliable security for your property.



FAQ:

1. Q: What is the resolution of the Hope-Wish PTZ Infrared Camera HP-TC?

A: The HP-TC has a resolution of 1080p Full HD.

2. Q: Is the HP-TC suitable for outdoor use?

A: Yes, the HP-TC is weatherproof and suitable for outdoor use.

3. Q: What is the night vision range of the HP-TC?

A: The HP-TC has a night vision range of up to 100 feet.

4. Q: Can I control the camera's movements remotely?

A: Yes, the HP-TC is a PTZ (Pan-Tilt-Zoom) camera that can be controlled remotely using a mobile app or web browser.

5. Q: Where is the Hope-Wish PTZ Infrared Camera HP-TC manufactured?

A: The HP-TC is manufactured in China.
