Product Details:
|
| Consumption: | 10W，808nm , NIR | Onvif: | Support |
|---|---|---|---|
| Fog Penetration: | AFR, Optional For Fog Filter | Ptz: | Load Duty：30kg |
| Lens: | 25mm | Connector: | Aviation Water-Proof Connector |
| Ir Laser: | 808nm | Dimensions: | 200mm X 100mm X 100mm |
| High Light: | Long Range Infrared Camera 10W,Long Range Ptz Ip Camera |
||
Key Benefits:
· Long range 24-hours monitoring.
· Delicate and smooth images．
· Convenient for installation and application.
· 360 degree of Omni-directional Pan-Tilt
· Super-strong aluminum alloy with IP66
· Higher sensitivity
· Effective in all environments
· Small size and low weight
Overview:
· VOx uncooled detector, 384*288 (640*512);
· NETD is less than 50mk (@25℃F1.0);
· SDE digital image processing, AGC, 2X digital amplification;
· 10 pseudo color and B/W, B/W inverse;
· Intelligent functions: cross-border/ intrusion detection and target tracking;
· 255 level alarm threshold can be setup
· Advanced algorithm support shot-point/ fire detection and alert;
· One integral aluminum alloy housing, water proof, IP66 weather proof, anti-dust.
| Model | HP-BTVC6307-2132 |
| Detection | Vehicle: 6,500m / Human: 2,500m |
| Identification | Vehicle: 1,800m / Human: 700m |
| Thermal Camera | |
| Sensor | 5th generation FPA VOx Detector |
| Resolution | 384 × 288 pixel(optional 640 × 512 pixel) |
| Spectral range | 7.5～14μm |
| NETD | 50mK (@25℃ F1.0) |
| Focal length | 25 - 75mm F1.0 |
| Field of view(horizontal) | 14.8° X 11° - 4.9° X 3.7°(optiona 24° X 18° - 8° X 6°) |
| Visible Camera | |
| Imaging Sensor | 1/2.8'' Star Level CMOS, Integrated ICR Dual Filter D/N Switch |
| Resolution | 2 million pixels, 1920 x 1080 |
| Illumination | 0.001Lux high sensitive color, 0.0001Lux black and white |
| Video Bit Rate | 32Kbps-16Mbps, 60Hz 30 frames/second, ABF auto adjustment |
| Focal Length | 8-320mm, 40X zoom, 2 Megapixel electric focus |
| PTZ | |
| Duty | 10 kg |
| Rotation | Pan: 0 - 360° continuously,Tilt: +90°～- 90° |
| Rotation speed | Rotation speed:Pan: 0.01～100°/S,Tilt: 0.01～60°/S, support lens focusing speed adaptive |
| Accuracy | ±0.1° |
| Preset | 255 presets, support lens zooming and focusing preset |
| Mode | Support 6 cruising line, 1 apple-skin scanning, 1 line-cruising |
| Network | |
| Network interface | RJ45.10, 10/100 Base-T adaptive (integrated video output RS422/485) |
| Network Protocol | TCP/IP, UDP, IPv4/v6; support HTTP, RTP, RTSP, NFS, DHCP, NTP, SMTP, SNMPv1/v2c/v3, UPNP, PPPoE, DNS, FTP; support PSIA, ONVIF2.0, GB28181 and other network protocol. |
| Environment Parameter | |
| Operating temperature | -25℃~+60℃(-40℃ Optional) |
| Storage temperature | -45℃～70℃ |
| Protection Level | IP66 |
| General | |
| Total Consumption | 50W |
| Power supply | AC/DC24V, anti-reverse connection protection |
| Weight | ≤8.5 kg (include PTZ) |
Brand Name: Hope-Wish
Model Number: HP-
Place of Origin: China
Lens: 25mm
Feature: IP66
Load Duty: 50kg
Onvif: Support
Consumption: 10W, 808nm, NIR
Hope Wish Photoelectronics Technology Co., Ltd. was established in Jinan high tech Zone and has a core R&D team for laser imaging, infrared thermal imaging detection and tracking technology research and product. Hope-Wish focuses on the research and development of night vision and multispectral imaging technology, by using a variety of image analysis and processing technology based on artificial intelligence to provide users with comprehensive optoelectronic system solutions in long-distance, high-definition, intelligent, multi-purpose, all-weather and complex environments.
