Product Details:
|
| Resolution: | 1920x1080 | Lens: | 25mm |
|---|---|---|---|
| Working Temperature: | -25℃～+55℃ (-40℃ Optional) | Ir Laser: | 808nm |
| Preset: | 80 （245 For Option） | Video Format: | H.264/MPEG4/MIPEG |
| Feature: | IP66 | Ptz: | Load Duty：30kg |
| High Light: | Onvif Supported Long Distance Surveillance Camera,Infrared Night Vision Telescope Surveillance Camera,Long Range HD Infrared Laser Camera |
||
BRC19 series HD infrared laser camera consist of infrared laser illuminator, PTZ platform, precise gearing, 2.1 megapixel HD lens, digital decoder, CCD and CU. The mechanical design of PTZ is simple and stable.
BRC19 camera could rotate to the proposed position quickly and accurately. The camera has 128 preset, recording and patrol function and could preset anywhere. It also have automatic exposure, automatic focus function.
Feature
| Model | HP-BRC1930 |
| Detection | Day: 800m |
| Night: 300m~420m | |
| Sensor | 1/2.8'' B&W CCD, 2.1 MP, 1920X1080, automatic ICR switch |
| Encoding | Video compression: H.264, code stream 32k～16Mbps,support dual stream, the heart, smart restructuring, electronic shutter, white balance, 3D DNR, DWDR, automatic exposure, support SD card, motion detection, mask alarm |
| Image setting | Lightness, contrast radio, saturation |
| Lens |
4.3～129mm,30 optical zoom F1.6～F5.0 |
| FOV | 65°～2.3° |
| Min.Illumination | 0.005lux B/W0.05lux Color/ |
| Consumption | 5W,808nm ,NIR |
| Laser lens | 30mm F1.0 Fast lens,GHT-II homogenizing |
| Laser angle | 2°～50° |
| Angle control | DSS digital illumination control,30ms fast track response, min 0.1° illumination zooming, manual/automatic |
| Optical axis aiming | 0.01°SLM automatic axis automatic aiming and locking ,reserved external interface, maintaining without take out the case |
| Pan rotation | 0°~360° continuously |
| Tilt rotation | -45°~+45° |
| Rotation speed | Pan: 0°~100°/s,Tilt: 0°~80°/s |
| Preset | 128 |
| Line scan | 3 path(User could set up the starting point, destination and scanning speed) |
| Patrol | 6 path(each path have 16 point, staying time is adjustable) |
| Customized function | Customizable privacy shade, 3D box chosen magnification |
| Interface | RJ45,10M/100M adaptive Ethernet,TCP/IP,RTP/RTCP,HTTP |
| Compatibility | Support ONVIF,GB/T28181 |
| Heat/demisting/ wiper | Yes |
| Laser switch | Auto/manual |
| Ingress protection | IP66,anti-lighting,anti surge |
| Operational temp. | -35~55℃ |
| Power supply | AC24V/2.5A,DC12V/3.5A, common≤40W,peak≤60W |
| Weight | 7kg |
Choose Hope-Wish for your Long Range Infrared Camera customization needs and experience the best in Infrared Night Vision Telescope, EO Ir Imaging Systems, and Long Range Surveillance. Contact us now to discuss your requirements and get a quote.
Hope Wish Photoelectronics Technology Co., Ltd. was established in Jinan high tech Zone and has a core R&D team for laser imaging, infrared thermal imaging detection and tracking technology research and product. Hope-Wish focuses on the research and development of night vision and multispectral imaging technology, by using a variety of image analysis and processing technology based on artificial intelligence to provide users with comprehensive optoelectronic system solutions in long-distance, high-definition, intelligent, multi-purpose, all-weather and complex environments.
