Product Details:
|
| Material: | Integral Aluminum Alloy Housing | Video Format: | H.264/MPEG4/MIPEG |
|---|---|---|---|
| Lens: | 25mm | Dimensions: | 200mm X 100mm X 100mm |
| Onvif: | Support | Load Duty: | 50kg |
| Working Temperature: | -25℃～+55℃ (-40℃ Optional) | Fog Penetration: | AFR, Optional For Fog Filter |
| High Light: | MPEG4 Infrared Thermal Imaging Camera,Infrared Thermal Imaging Camera Long Range,Aluminum Alloy Long Range Infrared Camera |
||
1. 8-320mm full HD visible camera, 2 mega pixels CCD, 1-10km detection range in the daytime.
2. 75mm/105mm /155mmthermal camera, 384*288/640*512 resolution, 1-18km detection range at day/night.
3.45mk NETD produces crisp thermal image under all weather conditions.
4. Fog penetration (optional), optical filtering and image
Processing
5.50kg load duty and 360 degree rotation.
6.IP66 ingress protection ensures camera´s proper functioning under tough weather conditions.
| Model | HP-HTVC6511-2132 |
| Detection | Vehicle: 8.6Km; Human:3.4km |
| Identification | Vehicle: 2.4km; Human: 900m |
| Thermal sensor |
VOx uncooled detector, 640*512 resolution 7.5um-14um spectral response, 45mk NETD |
| Thermal lens | 21mm~105mm |
| 5X continuous zoom, auto focus | |
| 8X digital zoom | |
| Image process |
1. Image enhancement: SDE digital image enhancement technology to enhance image details 2. Pseudo-color polarity: 16 kinds of pseudo-color images, hot black / hot white two polarities 3. Image parameters: AGC automatic gain control, brightness, contrast 4. Electronic zoom: 2×, 4×, support global synchronous display 5. NUC correction: automatic / manual correction, background correction |
| Enhancement |
1.Protection from strong light, Sunburn protection 2.Temperature correction: a thermalization design, the image sharpness is not affected by temperature 3. Scene mode: support multi-configuration scene, adapt to different environment application |
| Intelligent Analysic |
1.Intrusion detection; 2.Fire Alarm/Hot Alarm 3. Ranging Scale; 4.Support Auto Track (together with software) |
| Visible Camera sensor | 1/1.8'' CMOS |
| 0.0002lux super high sensitive color to B/W CCD | |
| 2.1 MP resolution | |
| Automatic ICR switch | |
| H.264/MPEG4/MIPEG | |
| 32Kbps~16Mbps,60Hz30 FPS | |
| Visible Camera lens | 8mm~320mm |
| 40X zoom | |
| Auto focus | |
| 2MP full HD resolution | |
| Housing | Material:High strength aluminum alloy shell,waterproof seal,To avoid the growth of mold and moisture generated |
| Structure:Integrated multi-window design | |
| Surface coating:PTA three-resistance coating, Seawater corrosion resistance | |
| Built-in thermostat, design of thermal equilibrium | |
| Interface:Aviation waterproof plug | |
| PTZ | Load:30kg/50kg |
| Pan: 0~360°, Tilt: +45°～-45° | |
| Speed:Pan: 0.01～30°/S, Tilt: 0.01～15°/S | |
| Preset: 255, with Petrol/scan function, Azimuth real-time display, Zero correction function | |
| Interface | RJ45 Interface |
| Video format | H.264, Dual video output |
| Protocol | TCP/IP,HTTP,DHCP,DNS,DDNS,RTP ect. Other protocol |
| Support ONVIF2.0 | |
| Pelco-P,Pelco-D,Baudrate 2400,4800,9600,19200 optional | |
| Power supply | AC24V/DC24V±10%,50Hz,150W,Standard AC220V->AC24V power supply |
| Environment | Operating temperature:-35℃～+60℃(-40℃ optional)；Storage temperature:-40℃～+65℃ |
| Humidity:<90% | |
| Anti-lighting:built-in auto Fuse-protected device, Power 4000V,Signal 2000V | |
| Ingress protection:IP66 |
Hope Wish Photoelectronics Technology Co., Ltd. was established in Jinan high tech Zone and has a core R&D team for laser imaging, infrared thermal imaging detection and tracking technology research and product. Hope-Wish focuses on the research and development of night vision and multispectral imaging technology, by using a variety of image analysis and processing technology based on artificial intelligence to provide users with comprehensive optoelectronic system solutions in long-distance, high-definition, intelligent, multi-purpose, all-weather and complex environments.
