Product Details:
|
| Lens: | 35 Mm | Tilt: | 90° |
|---|---|---|---|
| Resolution: | 640x480 | Focus: | Auto/Manual |
| Image Output: | HDMI, USB | Alarm: | Motion Detection, Temperature Alarm |
| Type: | PTZ Thermal Imaging Camera | Operating Temperature: | -20°C To +60°C |
| High Light: | 35 Mm Lens Thermal PTZ Camera,Manual Focus PTZ Thermal Imaging Camera,640x480 Resolution PTZ Thermal Imaging Camera |
||
This PTZ Thermal Imaging Camera is a perfect solution for surveillance and security applications. It features a 360° continuous rotation pan, 90° tilt, 35 mm lens, and an operating temperature range of -20°C to +60°C. It is equipped with advanced digital detail enhancement image processing functions, and is highly reliable and cost-effective. This thermal camera module is suitable for a wide range of applications, offering excellent thermal camera price and performance. It is the ideal thermal PTZ camera for any security and surveillance systems.
| Model | HP-TC61030 |
| Sensor |
1,Detector:5th generation UFPA Vox Detector ; 2,Resolution:640X512 3,NETD:50mK(@25℃ F1.0) 4,Spectral range:12μm |
| NETD | 50mK(@25℃ F1.0) |
| Focal length |
1,Length: 30～300mm, optical 10X zooming 2,FOV:1.5°×1.2 ~14.6°×11.7° 3,Motorized zoom,focus(auto focus optional ) 4,AS+DOE advanced optical design, high infrared transmission; 5,Applied 3CAM high precision design; |
| IFOV | 0.08～0.85mrad |
| Image processing | 1. stable operational temperature, starting time less than 4 seconds |
| 2. SDE digital image processing | |
| 3. 10 pseudo color and B/W, B/W inverse | |
| 4. AGC | |
| 5. 1~8X digital amplification | |
| Housing |
1,Material:aluminum alloy housing,waterproof; 2,Structure:Integral single window design ; 3,Surface:PTA coating, anti sea water corrosion; 4,Sealing rate:IP66 5,Built-in temperature controller,thermal balance design; 6,Interface:aviation waterproof connector ; |
| PT(optional) |
1,Load:50kg military level digital PT ; 2,Angle:pan 0～360°,tilt -45°～+45° 3,Speed:0.01～30°/S high precision variable speed control and locking ; 4,Preset:80 presets,support lens zoom and focus memory,variable speed scanning 0～30°/S ,support apple peel scanning function; 5,Protocol:Pelco-P,Pelco-D 6,Baud rate:2400,4800,9600,19200 optional ; |
| Consumption ,weight |
1,Consumption(PT included):min.40W,max.120W 2,weight(PT included):≤40kg |
| Interface | 1. RS-485(PELCO D protocol, baud rate 2400bps), RS-232(option) |
| 2. Remote OSD setting | |
| 3. PAL/NTSC video output | |
| 4. AC24V( DC12V option) | |
| 5. Waterproof connector | |
| Environment indicator |
1,Working temperature:-25℃～+55℃(-40℃ optional) 2,Storage temperature:-35℃～+75℃ 3,Humidity:<90% 4,Anti-shock:0.2g(GB/T15211—20135.4 harshest level 2 standard) 5,Anti-resistance:15g(GB/T15211—20135.3 harshest level 3 standard) 6,Anti salty:PH6.5～7.2,continuous spraying 48 hours ; 7,Protection rate:IP66 |
Hope-Wish HP-TC Thermal Imaging Camera is designed with a thermal sensor and auto/manual focus, which is perfect for a variety of applications. With a wide temperature range from -30°C To +70°C, it can be used in various scenarios. Moreover, it also features motion detection and temperature alarm for added safety. With an impressive 640x480 resolution, it can capture detailed images. This thermal camera module is also perfect for scope thermal, thermal ip camera applications, and more.
Hope Wish Photoelectronics Technology Co., Ltd. was established in Jinan high tech Zone and has a core R&D team for laser imaging, infrared thermal imaging detection and tracking technology research and product. Hope-Wish focuses on the research and development of night vision and multispectral imaging technology, by using a variety of image analysis and processing technology based on artificial intelligence to provide users with comprehensive optoelectronic system solutions in long-distance, high-definition, intelligent, multi-purpose, all-weather and complex environments.
Our customized PTZ Thermal Imaging Camera –Hope-Wish HP-TC is designed with a wide range of features to provide you with the perfect solution for your surveillance needs. Our camera features a 20x Optical Zoom, 95% RH humidity, Digital Detail Enhancement image processing, and a wide operating temperature range of -20°C to +60°C. It also offers a storage temperature range of -30°C to +70°C.
Our PTZ Thermal Imaging Camera –Hope-Wish HP-TC is the ultimate thermal ip camera and thermal ptz camera solution for any security application. With its advanced features, you can be sure that your surveillance system will be reliable and secure.
PTZ Thermal Imaging Camera Technical Support and Service includes:
