Product Details:
|
| Weight: | 500g | Type: | Monocular |
|---|---|---|---|
| Effective Visual Distance: | 700-1600m | Color: | Black |
| Netd: | <60mK@300k(F#1.0) | Fov: | 24° X 18° |
| High Light: | Security Patrol Thermal Infrared Monocular,Night Vision Scope Thermal Imaging Monocular,Military Thermal Imaging Handheld Monocular |
||
Overview:
HP-DM2013 is a very popular military grade multifunctional night vision product in the market. As a classic monocular low-light night vision device, high magnification - long viewing distance, large objective lens - strong light transmission, can be equipped with 2nd generation + or quasi-3rd generation (G450+) image intensifier tube according to customer needs . As a multifunctional monocular night vision device, it can be connected to mobile phones, cameras, etc. for night shooting and functional accessories. The diversity of optional accessories greatly expands the scope of use of this night vision device. This product has strong practicability and can be used for night hunting, night fishing, forest fire prevention, power line inspection, home security, public security night patrol, investigation and evidence collection, frontier anti-smuggling, etc. It is an ideal device for both military and civilian use.
Key Benefits:
1. The perfect combination of durability and fine workmanship.
2. The night vision device uses the 2nd generation + level image intensifier (DM2013), and can also be equipped with a higher level quasi-3rd generation (DM3013) intensifier, which is suitable for different budgets and task requirements.
3. Military-grade multi-layer coating standard: ultra-broadband multi-layer anti-reflection coating can suppress the broadband reflection of the glass surface of the lens, reduce light loss, and allow more light to pass through the lens to obtain a good observation effect.
4. A separate infrared intensifier can be selected to enhance the effect of night use and expand the scope of application; an optional sight accessory can be used as a simple night vision sight; it can be connected with digital cameras, cameras, camcorders, mobile phones, etc. to shoot at night use.
5. The spring embedded design of the battery cover ensures that the night vision device can better contact with the battery and the spring is not easy to be damaged, and it is also easier to replace the battery quickly.
6. The eyepiece visor, built-in IR light and low battery indicator (displayed in the eyepiece) enhance the user's concealment.
Kit includes:
Night vision device, Soft helmet, Carrying case, Manual, Lens cleaning cloth, Warranty card, Desiccant
Technical Specification:
| Model | HP-DM3015 |
| IIT | Gen3 |
| Resolution (lp/mm) | 57-64 |
| Photocathode type | GaAs |
| S/N (dB) | 21-24 |
| Luminous sensitivity (μА/lm) | 1500-1800 |
| MTTF (hrs) | 10,000 |
| Magnification | 5x |
| FOV (deg) | 40 |
| Detection distance (m) | 250-280 |
| Diopter (deg) | +5/-5 |
| Lens system | F1.2, 60mm |
| Range of focus (m) | 0.25--∞ |
| Dimensions (mm) | 235X77X61 |
| Weight (g) | 793 |
| Power supply (v) | 2.0-4.2V |
| Battery type (v) | 1 3V CR123A lithium battery |
| Battery life (hrs) |
80(w/o IR) 40(w IR) |
| Operating temperature(℃) | -40/+60 |
| Environmental rating | IP67 |
