Product Details:
|
| Highlight: | CE Infrared Thermal Camera,Higher Sensitivity Infrared Thermal Imaging Camera,Thermal Imaging Camera for Border Surveillance |
||
|---|---|---|---|
Key Benefits:
Long range 24-hours monitoring.
Delicate and smooth images.
Convenient for installation and application.
360 degree of Omni-directional Pan-Tilt
Super-strong aluminum alloy with IP66
Higher sensitivity
Effective in all environments
Small size and low weight
![]()
Overview:
VOx uncooled detector, 640*512 (384*288);
NETD is less than 50mk (@25℃F1.0);
SDE digital image processing, AGC, 2X digital amplification;
10 pseudo color and B/W, B/W inverse;
Intelligent functions: cross-border/ intrusion detection and target tracking;
255 level alarm threshold can be setup
Advanced algorithm support shot-point/ fire detection and alert;
One integral aluminum alloy housing, water proof, IP66 weather proof, anti-dust.
Applications:
Seaport and airport monitoring;
Water system monitoring;
Storage monitoring;
Military base security monitoring;
Oilfield & oil depot security;
Fire source prevention & monitoring;
Ecological and environmental monitoring;
Border and coastal defense;
Urban security and anti-UAV applications;
Highways and railways monitoring.
Technical specification:
| Model | HP-TC6307 |
| Detection | Vehicle: 6500m / Human: 2500m |
| Identification | Vehicle: 1800m / Human: 700m |
| Thermal Camera | |
| Sensor | 5th generation FPA VOx Detector |
| Resolution | 640 × 512 pixel (optional 384 × 288 pixel) |
| Spectral range | 7.5~14μm |
| NETD | 50mK (@25℃ F1.0) |
| Focal length | 25 - 75mm, 0.68 - 0.22mrad |
| Field of view(horizontal) | 24°×18° - 8°× 6° |
| PTZ | |
| Duty | 30kg CNC PT |
| Rotation | Pan: 0~360°, Tilt: -45°~+45° |
| Rotation speed | Pan: 0.01°~60°/S, tilt: 0.01°/S ~30°/S |
| Accuracy | ±0.1° |
| Preset | 255 presets, support lens zooming and focusing preset |
| Mode | Support 6 cruising line, 1 apple-skin scanning, 1 line-cruising |
| Network | |
| Network interface | RJ45.10, 10/100 Base-T adaptive (integrated video output RS422/485) |
| Network Protocol | TCP/IP, UDP, IPv4/v6; support HTTP, RTP, RTSP, NFS, DHCP, NTP, SMTP, SNMPv1/v2c/v3, UPNP, PPPoE, DNS, FTP; support PSIA, ONVIF2.0, GB28181 and other network protocol. |
| Environment Parameter | |
| Operating temperature | -25℃~+60℃(-40℃ Optional) |
| Storage temperature | -45℃~70℃ |
| Protection Level | IP66 |
| General | |
| Total Consumption | 180W |
| Power supply | AC/DC24V, anti-reverse connection protection |
| Weight | ≤25kg (include PTZ) |
