Product Details:
|
| Material: | Integral Aluminum Alloy Housing | Video Format: | H.264/MPEG4/MIPEG |
|---|---|---|---|
| Dimensions: | 200mm X 100mm X 100mm | Consumption: | 10W，808nm , NIR |
| Working Temperature: | -25℃～+55℃ (-40℃ Optional) | Ir Laser: | 808nm |
| Fog Penetration: | AFR, Optional For Fog Filter | Load Duty: | 50kg |
| High Light: | Ptz Long Range Infrared Camera,Long Range Infrared Camera 808nm |
||
Key Benefits:
· Long range 24-hours monitoring.
· Delicate and smooth images．
· Convenient for installation and application.
· 360 degree of Omni-directional Pan-Tilt
· Super-strong aluminum alloy with IP66
· Higher sensitivity
· Effective in all environments
· Small size and low weight
· VOx uncooled detector, 384*288 (640*512);
· NETD is less than 50mk (@25℃F1.0);
· SDE digital image processing, AGC, 2X digital amplification;
· 10 pseudo color and B/W, B/W inverse;
· Intelligent functions: cross-border/ intrusion detection and target tracking;
· 255 level alarm threshold can be setup
| Model | HP-BTVC6105-1930 |
| Detection | Vehicle: 4,200m / Human: 1,640m |
| Identification | Vehicle: 1,200m / Human: 470m |
| Thermal Camera | |
| Sensor | 5th generation FPA VOx Detector |
| Resolution | 384 × 288 pixel(optional 640 × 512 pixel) |
| Spectral range | 7.5～14μm |
| NETD | 50mK (@25℃ F1.0) |
| Focal length | 50mm F1.0 |
| Field of view(horizontal) | 7.4° X 5.6°(optional 12° X 9°) |
| Visible Camera | |
| Imaging Sensor | 1/2.8'' Star Level CMOS, Integrated ICR Dual Filter D/N Switch |
| Resolution | 2 Mega pixels, 1920 x 1080 |
| Illumination | 0.05 Lux high sensitive color, 0.01 Lux black and white |
| Video Bit Rate | 32Kbps-16Mbps, 60Hz 30 frames/second, ABF auto adjustment |
| Focal Length | 4.5 - 135mm 30X zoom, 2 Megapixel electric focus |
| PTZ | |
| Duty | 10 kg |
| Rotation | Pan: 0 - 360° continuously,Tilt: +90°～- 90° |
| Rotation speed | Rotation speed:Pan: 0.01～100°/S,Tilt: 0.01～60°/S, support lens focusing speed adaptive |
| Accuracy | ±0.1° |
| Preset | 255 presets, support lens zooming and focusing preset |
| Mode | Support 6 cruising line, 1 apple-skin scanning, 1 line-cruising |
| Network | |
| Network interface | RJ45.10, 10/100 Base-T adaptive (integrated video output RS422/485) |
| Network Protocol | TCP/IP, UDP, IPv4/v6; support HTTP, RTP, RTSP, NFS, DHCP, NTP, SMTP, SNMPv1/v2c/v3, UPNP, PPPoE, DNS, FTP; support PSIA, ONVIF2.0, GB28181 and other network protocol. |
| Environment Parameter | |
| Operating temperature | -25℃~+60℃(-40℃ Optional) |
| Storage temperature | -45℃～70℃ |
| Protection Level | IP66 |
| General | |
| Total Consumption | 50W |
| Power supply | AC/DC24V, anti-reverse connection protection |
| Weight | ≤8.5 kg (include PTZ) |
· Seaport and airport monitoring;
· Water system monitoring;
· Storage monitoring;
· Military base security monitoring;
· Oilfield & oil depot security;
· Ecological and environmental monitoring;
· Border and coastal defense;
· Highways and railways monitoring.
With its powerful 808nm IR laser and 25mm lens, the Hope-Wish Long Range Infrared Camera has the ability to provide long range surveillance, making it an ideal choice for border security, military use, and industrial inspection. Its high-resolution imaging and long-distance coverage make it a valuable asset in any surveillance operation.
The Hope-Wish Long Range Infrared Camera is a trusted product in military operations. Its advanced features and durability make it suitable for use in various military activities, including border surveillance, reconnaissance missions, and target tracking.
Hope Wish Photoelectronics Technology Co., Ltd. was established in Jinan high tech Zone and has a core R&D team for laser imaging, infrared thermal imaging detection and tracking technology research and product. Hope-Wish focuses on the research and development of night vision and multispectral imaging technology, by using a variety of image analysis and processing technology based on artificial intelligence to provide users with comprehensive optoelectronic system solutions in long-distance, high-definition, intelligent, multi-purpose, all-weather and complex environments.
