Product Details:
|
| NETD: | 50mK | Spectral Range: | 7.5～14μm |
|---|---|---|---|
| Image Storage: | 4G Memory Card | Resolution: | 336*256/640*512 |
| Power Consumption: | Power Consumption | Continuous Working Time: | > 5 Hours At No Record, >3.5 Hours At Record. |
| High Light: | Monocular Handheld Thermal Imaging Camera,50mK Handheld Thermal Imaging Camera,Long Distance Handheld Thermal Imaging Camera |
||
Key Benefits:
High sensitivity thermal module with 640 x 512 resolution
NETD < 35 mK (@25 °C,, F#=1.0)
Leading thermal image processing technology: Adaptive AGC, DDE, 3D DNR
1024 x 768 resolution 0.39-inch OLED display
Built-in rechargeable Li-ion battery
Up to 5.5 hours continuous operation
| Specification | |
| Thermal Module | |
| Image Sensor | VOx Uncooled Focal Plane Arrays |
| Resolution | 640 × 512 |
| Frame Frequency | 50 Hz |
| Pixel Interval | 17 μm |
| Response Waveband | 8 μm to 14 μm |
| NETD | Less than 35 mK (@25°C),F#=1.1 |
| Focal Length | 35 mm |
| IFOV | 0.49 mrad |
| Field of View | 17.7° × 14.2° (H × V) |
| Aperture | F1.0 |
| Magnification | 1.4 - 11.2 |
| Image Display | |
| Monitor | 0.39 inch, OLED, 1024 ×768 |
| Palettes | Black Hot, White Hot, Red Hot, Fusion |
| Uniformity Correction | Auto, Manual, External Correction |
| Digital Zoom | 1× , 2× , 4 ×,8× |
| Smart Function | |
| Hot Track | Yes |
| Detection Range | 1235 m |
| System | |
| Storage | Built-in memory module (16 GB) |
| Record Video | Yes |
| Capture Snapshot | Yes |
| Wi-Fi | Yes |
| Standby Mode | Yes |
| Power Supply | |
| Battery Type | Rechargeable Lithium Battery |
| Battery Operating Time | 5.5 hours continuous running with CVBS and Wi-Fi hot spot function off (@25 °C) 4.5 hours continuous running with CVBS and Wi-Fi hot spot function on (@25 °C) |
| Battery Capacity Display | Yes |
| General | |
| Power | 5 VDC/2 A, 2 W, Type-C Interface |
| Work Temperature/Humidity | From -30°C to 55°C (-22°F to 131°F); Humidity: 90% or Less |
| Protection Level | IP67 |
| Dimension | 201.6 mm × 73.7 mm × 66 mm (7.94" × 2.90" × 2.60") |
| Weight | 500 g (0.55 lb) |
